Automatic Aluminum Tube Offset Color Printing Machine - 2230x1600x1800mm, White, 4000w Power With 60 Pcs/min Production Capacity, Efficient Intermittent Conveyor Operation
Price: 39000 USD / Set
Get Latest Price
Minimum Order Quantity :
1 Set
Brand Name :
Yr
In Stock
Product Specifications
| Product Type | Other |
| Technology | Other |
| Power Source | Electricity |
| Operating Type | Automatic |
| Power | 4000 Watt (w) |
| Pressure | 0.6 mpa |
| Surface Treatment | Painted |
| Dimension (L*W*H) | 2230*1600*1800 Millimeter (mm) |
| Weight (kg) | 4200 Kilograms (kg) |
| Color | White |
| Warranty | Yes |
| Production Capacity | 60 Pcs/min |
| FOB Port | Shanghai |
| Supply Ability | 50 Per Year |
| Delivery Time | 30 Days |
| Sample Available | Yes |
| Sample Policy | Contact us for information regarding our sample policy |
| Packaging Details | Standard Export Packaging |
| Main Export Market(s) | Asia, North America, Middle East |
| Main Domestic Market | All India |
| Certifications | CE |
Product Overview
Key Features
The equipment can automatically insert the tubes from the pin of the conveyor chain that need to be printed on the mandrel for printing, and can automatically send the printed tubes to the pin of the conveyor chain for drying.
If no tube on the mandrel, the equipment can yield automatically through the proximity switch and the cylinder switch to avoid the mandrel being printed with ink.
This equipment converts the continuously running conveyor chain into intermittent movement through the eccentric movement of an eccentric wheel. When the conveyor chain pauses for a short time, the gripper will unplug the printed tube from the mandrel and insert the conveyor chain pin so that the tubes can enter the oven.
If no tube on the mandrel, the equipment can yield automatically through the proximity switch and the cylinder switch to avoid the mandrel being printed with ink.
This equipment converts the continuously running conveyor chain into intermittent movement through the eccentric movement of an eccentric wheel. When the conveyor chain pauses for a short time, the gripper will unplug the printed tube from the mandrel and insert the conveyor chain pin so that the tubes can enter the oven.
Company Details
It is all technology in machines that makes a difference in production. So, if you are on a lookout for latest technology machines for printing, sealing, packaging, and other works, then, trust Wuxi Xinrun Packaging Machinery Technology, a Wuxi, Jiangsu, China located manufacturer and exporter of Base Coating Machine, Aluminium Extrusion Press Machine, Automatic Box Packing Machine, Vacuum Toothpaste Mixer, MIC Filling Sealing Machine and many more machines. From the last 22 years, we have been introducing modern functionality machines with a view of benefitting sm
Business Type
Exporter, Manufacturer, Distributor, Supplier
Employee Count
80
Establishment
2001
Working Days
Monday To Sunday
