1325 Cnc Router For Woodworking - 1300x2500 Mm Working Area, 3.0 Kw Water Cooling Spindle, Hiwin Guideway , High Precision, Stepper Motor, Vacuum Table, Nc Studio

We are exporting of 1325 CNC Router for Woodworking in Zibo, Shandong Sheng, China.

1. Taiwan Hiwin square guide rail, gear wheel for X and Y axis, and ball screw for Z axis ,high precision and high speed
2. with vacuum adsorption table
3. 3KW water cooling spindle
4. Type3 and Wentai software
5. Stepper motor
6. NC Studio control system, of course, if you want to chang to DSP, it's OK. But please tell me first.

Specifications
Model
LD-1325
Working Area
1300*2500*150 mm
Spindle
3.0 kw, 24000 rpm, air cooling spindle ( water cooling spindle optional)
Table
vacuum adsorption table
Transmission
Rack and pinion for x.y, ballscrew for z
Guideway
HIWIN/AMT/PMI linear guideway
Resolution
0.01 mm
Speed
15 m/min
Driver
Microstepping drivers and stepping
Code
G Code, HPGL Code
Power Supply
AC220V/50Hz
Controlling System
Ncstudio control system(DSP optional)
Software
Type3 software, Ucancam software, Artcam software
Software Environment
WindowsXP/7
Packing
plywood box
Net Weight
1200 kg
Working travel
X axis:1300mm; Y axis:2500mm; Z axis:200-450mm or depends on customers
