About Of Hdmi Video Game Capture Recorder Full Hd1080p, 60fps Live Streaming Device Hd60.

About Of HDMI Video Game Capture Recorder Full HD1080P, 60FPS Live Streaming Device HD60.

Part number
HD60
Input Resolution
1920x1080 (60p) 1920x1080 (50p) 1920x1080 (30p) 1920x1080 (25p)
1920x1080 (24p) 1920x1080 (50i) 1920x1080 (60i) 1280x720 (60p) 1280x720
(50p) 720x480 (60i/p) 720x576 (50i/p)

Output Resolution
Maximum 1920x1080 1280x720i 60pi pass-through
Recording
Main body recording resolution: 1920 x 1080 (60 p). 1280 x 720 (60 p). 720 x 480 (60 p) Recording resolution in PC mode: 1920 x 1080 (30 p). 1280 x 720 (60 p).

Output Format: MP4 (H.264)
Composite Input: Dedicated Cable Included
NTSC, PAL: Input slot
HDMI, AV, MIC, USB: Output slot
HDMI, micro USB (PC), earphone, speaker
Supported File Systems: FAT32, FAT
Supported Capacity Maximumi 4GB/file
Bit Rate Maximumi 30Mbps
Supported Storage Capacity (Maximum value): 4 TB (HDD), 128 GB (USB disc), 128 GB (SD card)
Power Supply: DC 5V, 2A
Details of Hardware
CPU
HDMI standard: HDMI1.4
HDMI loop out: 1 HDMI loop out slot
SD slot: 1 SD slot
USB type A: Support Maximum value 4 TB (HDD), 128 GB (USB disc), 128 GB (SD card)
AV
SD analogue signal
DC
DC slot
Monitor
Resolution: 480x234 / 3.5a
Microphone/ Earphone
1x 3.5mm slot
Speaker
1W
LED signal lamp
The red lamp means limited storage i i 15%i
Battery life
3 hours
Size
160x73x20 mm
Details of software
OS
Linux
Vision
English / Chinese
OSD
3.5a LCD monitor
Date/time
Earphone volume adjust
Microphone volume adjust
Choose SD or USB storage
Adjust HDMI output resolution:1920x1080P30 / 1280x720P60 / 720x480P60
Choose HDMI or AV input signal
Reset
Replay video and photo
Setup presetting time
Snapshot

Package Contents
HD60 main unit, instruction manual and warranty card, dedicated remote control, HDMI cable, AV connection cable, USB power cable and USB power adapter
