Bourdon Operated Pressure Gauge - Stainless Steel 316l, Dial Size: 100-250 Mm | Weatherproof Ip-65, Micrometer Zero Adjustable, Glycerine Filled Option
Price: 430 INR / Piece
Get Latest Price
Minimum Order Quantity :
1 Piece
Brand Name :
H.guru
In Stock
Product Specifications
Color | Black Anodised |
Product Type | Pressed Steel Pressure Gauge |
Accuracy | 2 % |
Main Domestic Market | All India |
Product Overview
Key Features
Ref. Standard : IS 3624
Dial Size : 100, 150, 250 mm (Die cast aluminium case) & 100, 150 mm (SS 304 & 316 case)
Accuracy : 0.5% & 1%
Sensing Element : Bourdon Tube (SS 316L)
Connection Material : SS 316L
Movement : SS 304
Case : Die cast aluminium & SS 304 with Bayonet Bezel as a standard (SS 316 Optional)
Protection : Weatherproof to IP-65 (IS13947 Part I)
Process Connection : , , , BSP & NPT Male, M 20 X 1.5
Dial : Aluminium white background with black letters
Pointer : Micrometer zero adjustable (Black aluminium)
Window : Plane & Toughened glass
Mounting : Direct/Projection with Bottom & Back entry
Blow out disc : Provided
Suitability : -20 Deg C to +60 Deg C (Service Temperature)
Over range : 130% (FSD)
Optional : Glycerine Filled, Electric Contact
Accessories : Syphon, Gauge cock, Snubber, Needle valve
