Hitec Hs-7980th Mega Torque Hv Coreless Titanium Gear Servo

Applications for the HS-7980TH include high performance Giant Scale Aircraft, Truggies and Buggies, Fast Power boats, the largest aircraft, monster trucks or anywhere else you can use 600+ inch ounces of torque.

Hitec's strongest servo period, the "Monster Torque" HS7980TH is designed to operate on a two cell LiPo Pack. Featuring our newest high resolution "G2.5" 12 bit generation programmable digital circuit and our indestructible Titanium gears, The HS-7980TH has the performance and durability you've come to expect from a Hitec servo. Other features in the HS7980TH include a 7.4V optimized coreless motor, integrated heat sink case, and a top case with two hardened steel gear pins supported by axial brass bushing.

HS-7980TH Servo Specifications
Performance Specifications
Operating Voltage Range (Volts DC)6.0V ~ 7.4V
Speed (Second @ 60A )0.21 ~ 0.17
Maximum Torque Range kg. / cm.36.0 ~ 44.0
Current Draw at Idle10 mA
No Load Operating Current Draw480 mA
Stall Current Draw9,900 mA
Dead Band Width1 Aus


Physical Specifications
Dimensions (mm)43.8 x 22.4 x 40.0
Weight (Gram)78.2
Circuit TypeG2 Programable Digital
Motor TypeCoreless Metal Brush
Gear MaterialTitanium
Bearing TypeDual Ball Bearing
Output Shaft (type / A mm)Standard 24
Case MaterialPlastic / Aluminum
Dust / Water ResistanceSplash Proof
Connector Gauge (AWG) / Strand Count22 / 60
