Smf Battery By Aashirwad Motors

SMF Battery Nominal Voltage 12 Rated Capacity (20 hour rate) 7.2 Ah Dimensions mm (inch) Length 151 mm (5.94 inches) Width 65mm (2.56 inches) Height 96mm (3.78 inches) Total Height 101mm (3.97 inches) Approx. Mass 2.54 kgs Characteristics Capacity 27 oC (77 oF) 20 hour rate to 10.5 ECV 7.2 Ah 10 hour rate 10.5 ECV 6.7 Ah 5 hour rate to 10.5 ECV 6.15 Ah 1 hour rate to 10.5 ECV 4.5 Ah Internal resistance Fully charge battery at 27 oC <25 milli ohms Capacity affected by temperature (20 hrs rate 104 oF (40 oC) 110% 81 oF (27 oC) 100% 32 oF (0oC) 80% 5 oF (-15 oC) 60% Self discharge at 27 oC Capacity after 3 month storage 88% Capacity after 6 month storage 78% Maximum discharge current for 5 sec at 27 oC 108 Amps Charge method (Constant Voltage) Cyclic use (Repeating use) Initial current 1.8 Amps Control Voltage 14.2V to 14.4 V Trickle use Initial current 0.72 Amps Control voltage 13.5 V to 13.8 V
