Under Crank Shearing Machine - Rigid Steel Frame, 1270x4mm Cutting Capacity | Mechanical Hold Down System, High-quality Four-edged Knives, Hand-operated Lubrication System

Under Crank Shearing Machine @page { margin: 0.79in } td p { margin-bottom: 0in } p { margin-bottom: 0.1in; line-height: 120% } Standard Machines have been designed and developed through structural analysis technique for continuous production, accuracy and repeatability. Frame : Rigid steel frame of Standard Shears are optimally designed to avoid weak sections at load supports and is of interlocked design. The ram is guided throughout its length by accurate machined guideways ensuring proper clearance and clean cut. Hold - Down System : Spring loaded mechanical Hold down pads hold the sheet securely, to avoid slipping and bowing resulting in clean square cuts. Hold down units are provided with oversize pads to avoid impressions on sheet metal on request. Knives : Standard Shears are provided with high quality single segment (Hchr) knives for longer tool life. Ease in assembling of knife reduces down-time. The knife blades are four edged. Lubrication : All bearing parts and guide surfaces are lubricated through hand-operated lubrication system. Mechanical back gauge : This is a Standard equipment provided on all Standard shears. Scale on the back gauge gives instantaneous reading of distance between shear and back gauge. Thus avoiding errors and maintenance encountered in electronic equipment. Standard Accessories : Gear & wheel guard, Hand operated back gauge, Manual lubrication system. T - slot front supporters, Front scale gauge, Mechanical hold down & Instruction manual. Note : Electricals are not under Warranty. Model Cutting Cap. In M.S.Length x Thickness Depth of throat Stroke per minute Table height Table width Front Guage Rear Guage Motor HP/KW Blade length x width x thick Overall dimension in mm(approx) Length A Breadth B Height C SS-1 1270x4 80 50 900 450 600 750 5/3.7 1270x63x12 2290 2000 1525 SS-2 1525x4 80 50 900 450 600 750 5/3.7 1525x63x12 2540 2000 1525 SS-3 2030x4 80 50 900 450 600 750 7.5/5.6 2030x63x12 3050 2000 1525 SS-4 2540x4 80 50 900 450 600 750 10/7.7 2540x75x18 3550 2000 1525 SS-5 3125x4 80 50 900 450 600 750 12.5/9.5 3125x75x18 4200 2000 1525
