Pressure Switch Wika / Indfoss Ips 200 Psm 520 - 200

Series GH 901 Sensor Type SS 316 L Bellow Wetted Parts SS 316 Enclosure Aluminium Pressure Die Cast Weatherproof To Ip:66 On/Off Differential Fixed : Within 6% Range 4.0 to 25 Bar Maximum Working Pressure 36 Bar Process Connection 1/4 NPT (F) Micro Switch 1x SPDT (1 NO + 1 NC) Micro Switch Rating AC Rating ? 15A, 250V / DC Rating ? Resistive : 0.5A 110V / 0.25A 220V / 8A 24V Electrical Entry 3/4 ET Nylon Cable gland for 8 mm OD cable Maximum Fluid Temperature 170 Deg C


Applications
Pumps
Compressors
Special features
Adjustable on site
Protection cap for switch point adjustment
Setting ranges:
-0.4 ... +7 to 6 ... 30 bar
-6 ...100 to 85 ... 425 psi
-0.04 ... +0.7 to 0.6 ... 3 MPa
Electrical rating up to AC 230 V, 50/60 Hz, 10 A
Description


The PSM-520 is used in industrial control, monitoring and alarm applications.
The switch point can be specified by the customer on site.

The instrument can switch electrical loads of up to AC 230 V, 50/60 Hz, 10 A.





The PSM-520 pressure switch offers many application possibilities with non-corrosive media like oil, wate
